The Optilab EDFA-GB-R is a line of Gain Flattening Erbium-Doped Fiber Amplifiers are designed for in-line amplification of DWDM networks. When a standard EDFA is used to amplify multi-channel DWDM signals, the output power level of various channels will vary according to the gain profile of the erbium fiber. This gain variation can be as great as 6 dB in magnitude. The EDFA-GB-R is unique in its dual-stage amplification and internal Gain Flattening Filter (GFF) to compensate the erbium fiber gain variation.

Features:
• Compatible with 10 Gb/s and 40 Gb/s
• Channel spacing of 100 GHz or 50 GHz
• Flatten gain amplification 1530 nm to 1560 nm
• Amplify 8 to 64 DWDM channels
• High output power up to +24 dBm
• Two 980 nm pump lasers
• Two 1480 nm pump lasers
• 3 year warranty standard
